solid carbide end mill cutter with chamferP-3912
TOP 80 SWISS GRADE

ORDER CODEP-3912
Solid carbideCarbide
Our price$88

PRODUCTS DETAILS
PRODUCT REVIEWS

specification
quick details
description
packing

specification

Order code	Raise ref	material	d.mm	Replaceable cutters Ref	price	Quantity	Add to cart
P-3912	W302	Carbide	2.0	D737688ZB	$88

Quick details

QUICK DETAILS

Order code:P-3912
RAISE Ref. :W302
Material:Carbide
For machine:Compatible with Electronic key cutting machine,Viper,QUATTROCODE,TRIAX QUATTRO,TRIAX -e.code,KABA ILCO TRICODE HS
D[mm]:6
d[mm]:2.0
L[mm]:40
Replaceable cuttersD737688ZB
*Click the machine name to get all the cutters for this machine

1
For machineCompatible with Electronic key cutting machine,Viper,QUATTROCODE,TRIAX QUATTRO,TRIAX -e.code,KABA ILCO TRICODE HS
2
Same size 60 series milling cutter W302M
3
FEATURES 1.Material: Ultra-high hardness and high wear-resistant carbide material from Sweden, ultrafine grain and good wear resistance2.Manufacturing process: Full automatic grinding center with high gloss grinding, sharp and low noise, unique 90° oblique edge design.3.Features: Chamfer craft, can mill chamfer of keyway at one time, completely remove the burrs of the incision, make the incision smooth, accurate size, high precision of cutting edge 0.005mm, edge sharp4.Advantages: Spiral groove with chamfer design, sharp, can cut brass key and nickel silver copper key. The key groove is formed with the chamfer at one processing and the incision is smooth.

SUIT FOR PROCESSING KEYS

All internal milling slot key, suitable for processing nickel silver copper keys, can efficiently process original high hardness key blanks, such as Honda original keys, STRATTEC key blanks etc.

P-3896

Product Video

55, 60, 80 end mill series difference table

	55 COMMON GRADE	60 UNIVERSAL GRADE	TOP 80 SWIss GRADE
Material	Material with good breaking resistance	Material compatible with wear and break resistance	The High Hardness and the longest-wearing type material
For key	Civil key and copy car key	Mainly for copy key	Original high hardness key
For machine	Mainly for Manaul type key duplicator machine	Mainly for CNC key duplicator machine	CNC key duplicator machine
processing	High accuracy grinding	High gloss grinding on flute	Mirror grinding on the flute
Tolerance	0.01mm	0.01mm	0.005mm
Using life	More than 30 pieces multitrack key	Cutting 100 pieces keys	Cutting 100 pieces original Nickel Silver keys
